IT Site Survey Software
Draw the floor plan, mark access points, data points and cable runs, and keep each room's measurements, photos and issues one click behind it.
Free forever on the Personal plan
Site surveys: an example
The plan, room by room
Rooms laid out as built, each holding what the survey proposes for it.
Access points and cable runs
Proposed positions with measured run lengths, ready for the installer.
Photos and notes per room
Measurements, photos and issues open from the room they describe.
The basics
What is an IT site survey?
An IT site survey records the physical facts a project depends on before anything is installed: the rooms and their uses, where the comms cabinet can go, power and ventilation, cable routes and lengths, Wi-Fi coverage and anything that blocks it, and the issues a builder or client must fix first.
MSPs run site surveys before fit-outs, office moves, Wi-Fi upgrades and new sites. A survey only helps if the installer, the builder and the client can each find the answer they need, which is hard in a spreadsheet of notes beside a folder of photos.
In Blueprintr the survey is a floor plan, and every room opens a stratum with its measurements, photos and issues, so the plan and the notes are one document everyone on the project can use.
Why Blueprintr
Site surveys installers can work from
The floor plan on one canvas, the surveyor's notes behind every room.
Floor plans from containers
Draw each room as a container where it sits in the building, and put the access points, data points and cabinet inside the room they belong to.
VellumNotes and photos behind rooms
Give each room a stratum with its measurements and issues, and an image tab for the photos taken on the day.
StratumIssues where they are
Mark each issue as a red tile in the room it affects, with a stratum saying who fixes it and by when.
The cabinet, unit by unit
Plan the comms cabinet with Vellum's native rack shapes, as a sub-diagram behind the comms room, so every U is agreed before install.
Draw over the architect's plan
Place the building plan as an image on the canvas and draw rooms and equipment on top, so positions match the drawings.
One link for the builder
Send the builder and the client an unlisted link. They can open every room's notes without an account.
Blueprints
How to
How to record a site survey in Blueprintr
Create a blueprint
Sign up free and create a blueprint for the site, in the client's team or portfolio.
Draw the floor plan
Add a container for each room, laid out as the building is, or draw over the architect's plan.
Mark what goes where
Add access points, data points and the cabinet, and draw each cable run with its measured length.
Add notes and photos
Right-click each room and add a stratum with measurements, photos and the issues to fix.
Share it
Send the link to the installer, the builder and the client, and update it after each visit.
FAQ
Questions about site surveys
Is this site survey software free?
Yes. The Vellum editor, rack shapes, strata and image tabs are on the free Personal plan, in the browser and in the desktop app.
What should an IT site survey include?
Every room and its use, the cabinet location and its power, data points per room, access point positions with test readings, cable routes and lengths, issues to fix with an owner, and photo references.
Can I add photos to a site survey?
Yes. A stratum can have image tabs, uploaded or linked, and its rich text can include images, so each room's photos open from the room on the plan.
Does Blueprintr create Wi-Fi heatmaps?
No. Blueprintr records the survey; it does not measure coverage. Take readings with your survey tool and record them in the room's stratum, as the example does for each access point.
Can I use the architect's floor plan?
Yes, as an image. Place it on the canvas and draw rooms, access points and cable runs over it, so positions match the drawings.
Can the builder see the survey without an account?
Yes. Publish the blueprint as unlisted and send the link; anyone with it can open the plan and every room's notes. On Premium you can add a password.
